Kibblewhite Valve Guide - C630 Bronze - 30-4069
Produktinfo
- Artikelnummer
- KW304069
- Herstellernummer
- 30-4069
- Position
Upgrade your engine's performance and reliability with the Kibblewhite C630 Valve Guide. Manufactured in the USA from high-quality materials, this valve guide is designed for both intake and exhaust applications, ensuring optimal valve seating and heat dissipation.
Description
The Kibblewhite C630 Valve Guide is crafted from copper-based C63000 nickel-aluminum bronze, offering exceptional durability and heat conductivity. The 5% nickel content provides superior resistance to wear, extending the life of your valve train components. The approximately 80% copper content efficiently dissipates heat, preventing valve damage and maintaining consistent performance under demanding conditions. Its precisely engineered profile minimizes airflow disruption, maximizing engine efficiency while ensuring critical cross-sectional thickness in high-temperature areas. This design promotes both high performance and endurance, making it an ideal choice for enthusiasts and professionals seeking to enhance their engine's capabilities. Install Kibblewhite valve guides for improved valve train longevity and optimal engine performance. Each valve guide is meticulously manufactured to meet exacting standards, guaranteeing a precise fit and reliable operation.
Features & highlights
- Made in the USA from premium C63000 nickel-aluminum bronze.
- 5% nickel content enhances wear resistance for extended lifespan.
- 80% copper content provides superior heat conductivity, preventing valve damage.
- Optimized profile minimizes airflow disruption for maximum engine efficiency.
- Maintains critical cross-sectional thickness in high-temperature areas for enhanced endurance.
- Designed for both intake and exhaust applications.
Technical specifications
- Brand: Kibblewhite
- Vendor Part Number: 30-4069
- Application: Exhaust, Intake
- Inside Diameter: 0.2155"
- Outside Diameter: 0.4372"
- Material: C630 Bronze
- Product Name: Valve Guide
- Units: Each
Important to know
Valve guides are sold individually.
- Brand
- KIBBLEWHITE
- Vendor part number
- 30-4069
- Product name
- Valve Guide
- Outside diameter
- 0.4372"
- Inside diameter
- 0.2155"
- Application
- Exhaust, Intake
- Material
- C630 Bronze
- Units
- Each
