Magnum Shielding 1-1/4" Handlebar Kit

Upgrade your motorcycle with a complete handlebar solution. The Magnum Shielding 1-1/4" Caliber Handlebar Installation Kit provides everything needed for a seamless handlebar upgrade. This kit combines high-quality construction with a stunning appearance, ensuring both performance and style.

Description

This comprehensive kit features Magnum's 1-1/4" Caliber handlebars, known for their exceptional quality and design. The handlebars are meticulously crafted with machined control mounts, eliminating weak points and ensuring a secure fit. The high-luster finish adds a touch of elegance to your bike. Pre-drilled and notched for throttle-by-wire, these handlebars are also preloaded with E-Z pull-thru sleeving, simplifying the internal wiring process. The kit includes throttle and idle cables (or throttle-by-wire extensions), a clutch cable or hydraulic clutch line, brake lines, copper crush washers, hardware, and necessary switch wiring or turn signal extensions. Cables are designed for low effort and high efficiency, meeting or exceeding OE specifications.

Features & highlights

• Complete handlebar kit with matching braided cables and brake lines.
• 1-1/4" Caliber handlebars with machined control mounts for superior strength.
• High-luster finish for an outstanding appearance.
• Pre-drilled and notched for throttle-by-wire, simplifying installation.
• E-Z pull-thru sleeving pre-installed for easy wiring.
• Low-effort, high-efficiency cables exceeding OE specifications.
• Assembled in the USA.

Technical specifications

• Brand: Magnum Shielding
• Handlebar Diameter: 1-1/4" (32 mm)
• Clamping Diameter: 1" (25.4 mm)
• Controls Diameter: 1" (25.4 mm)
• Center Width: 7-3/4" (19.5 cm)
• End Rise: 13" (33 cm)
• Rise: 14" (35.5 cm)
• Width: 34-1/2" (87.5 cm)
• Pullback/Sweep: 8" (20.5 cm)
• Material: Steel
• Finish: Chrome
• Features: Pre-Drilled, Notched for Throttle-By-Wire, Knurled Center
• Type/Bend: Installation Kit, Ape Hanger
• For Non-ABS Models

Important to know

Caliber Handlebars have a 1" diameter center section and fit 1" risers. Models originally equipped with handlebars that have a center section diameter larger than 1" will require changing the risers to a 1" ID version. Examples would be, but not limited to FLSTF, FLSTFB and CVO models. Please check before ordering.
