NGK Iridium IX Spark Plug - 7803

Experience the pinnacle of spark plug technology with the NGK Iridium IX Spark Plug. Designed for ultimate performance and longevity, this spark plug delivers enhanced ignition and fuel efficiency for your motorcycle. Upgrade your ride with NGK, the industry leader in spark plug innovation.

Description

The NGK Iridium IX Spark Plug DPR7EIX9 represents a significant advancement in spark plug technology. Featuring an iridium electrode that is significantly smaller than both platinum and conventional nickel electrodes, this spark plug ensures a more focused spark, leading to improved combustion and engine performance. The ultra-small diameter center electrode not only reduces the voltage requirement, extending the life of your ignition system, but also enhances overall engine responsiveness. The new metal shell plating offers superior anti-corrosion properties, ensuring durability and consistent performance over time. This resistor-type spark plug with a 12 mm thread size and 19.1 mm (3/4") thread reach is designed to deliver reliable ignition under a wide range of operating conditions.

Features & highlights

• Experience enhanced ignition and superior performance with the ultra-fine Iridium electrode.
• The reduced voltage requirement extends the life of your motorcycle's ignition system.
• Enjoy improved fuel efficiency and throttle response.
• Benefit from the anti-corrosive metal shell plating for increased durability.
• Designed for optimal combustion and reduced emissions.
• Necked Down center electrode provides better spark focus.

Technical specifications

• Brand: NGK Spark Plugs
• Part Number: DPR7EIX9 / 7803
• Center Electrode Type: Necked Down
• Electrode Tip Material: Iridium
• Heat Range: 7
• Electrical Resistance: 5k Ohms
• Thread Size: 12 mm
• Thread Reach: 19.1 mm (3/4")
• Hex Size: 17.5 mm (11/16")
• Spark Gap: 0.9 mm
• Ground Electrode Configuration: Single
• Ground Electrode Shape: Grooved
• Center Electrode Projection: Projected
• Terminal Configuration: Threaded Stud
• Type: Resistor

Important to know

Ensure this spark plug is compatible with your motorcycle's make and model before installation. Always refer to your motorcycle's service manual for proper installation procedures and torque specifications.
